3. How to Install

3.2.6. Rated Power

3
Enclosure type
Enclosure IP
protection NEMA
High overload rated
power - 160% over-
load torque
Enclosure type
Enclosure IP
protection NEMA
High overload rat-
ed power - 160%
overload torque
NB!
The F enclsoures have four different sizes, F1, F2, F3 and F4. The F1 and F2 consist of an inverter cabinet on the right and rectifier
cabinet on the left. The F3 and F4 have an additional options cabinet left of the rectifier cabinet. The F3 is an F1 with an additional
options cabinet. The F4 is an F2 with an additional options cabinet.
24
D1
21/54
Type 1/ Type 12
90 - 110 - kW at 400 V 132 - 200 kW at 400 V
(380 - 500 V)
37 - 132 kW at 690 V 160 - 315 kW at 690 V
(525-690 V)
E1
21/54
Type 1/ Type 12 Chassis
250 - 400 kW at 400 V 240 - 400 kW at 400 V
(380 - 500 V) (380 - 500 V)
355 - 560 kW at 690 V 355 - 560 kW at 690 V
(525-690 V) (525-690 V)
MG.33.U2.02 - VLT
D2
21/54
Type 1/ Type 12 Chassis
90 - 110 - kW at 400 V
(380 - 500 V) (380 - 500 V)
37 - 132 kW at 690 V
(525-690 V) (525-690 V)
E2 F1/F3
00 21/54
Type 1/ Type 12
450 - 630 kW at 400 V
(380 - 500 V)
630 - 800 kW at 690 V
(525-690 V)
® is a registered Danfoss trademark
®
VLT Automation Drive FC 300
Operating Instructions High Power
D3 D4
00 00
Chassis
132 - 200 kW at 400 V
(380 - 500 V)
160 - 315 kW at 690 V
(525-690 V)
F2/F4
21/54
Type 1/ Type 12
710 - 800 kW at 400 V
(380 - 500 V)
900 - 1000 kW at 690 V
(525-690 V)
