3.1.6 Rated Power

Frame size
3 3
Enclosure
protection
High overload rated
power - 160%
overload torque
Table 3.3 Rated Power, Enclosure Type D
Frame size
Enclosure
protection
High overload
rated power -
160% overload
torque
Table 3.4 Rated Power, Enclosure Types E and F
NOTICE
The F enclsoures have 4 different sizes, F1, F2, F3 and F4. The F1 and F2 consist of an inverter cabinet on the right and
rectifier cabinet on the left. The F3 and F4 have an additional options cabinet left of the rectifier cabinet. The F3 is an
F1 with an additional options cabinet. The F4 is an F2 with an additional options cabinet.
18
D1
IP 21/54
NEMA Type 1/Type 12
90-110 kW at 400 V
(380-500 V)
37-132 kW at 690 V
(525-690 V)
E1
IP 21/54
NEM
Type 1/Type 12
A
250-400 kW at 400 V
(380-500 V)
355-560 kW at 690 V
(525-690 V)
®
VLT Automation Drive FC 300 Operating Instructions
D2
21/54
Type 1/Type 12
132-200 kW at 400 V
(380-500 )
160-315 kW at 690 V
(525-690 V)
E2
00
Chassis
240-400 kW at 400 V 450-630 kW at 400 V
(380-500 V)
355-560 kW at 690 V 630-800 kW at 690 V
(525-690 V)
MG33U402 - Rev. 2013-12-16
D3
00
Chassis
90-110 kW at 400 V 132-200 kW at 400 V
(380-500 V)
37-132 kW at 690 V 160-315 kW at 690 V
(525-690 V)
F1/F3
F4 F2
F3 F1
21/54
Type 1/Type 12
710-800 kW at 400 V
(380-500 V)
900-1200 kW at 690 V
(525-690 V)
D4
00
Chassis
(380-500 V)
(525-690 V)
F2/F4
21/54
Type 1/Type 12
(380-500 V)
(525-690 V)
