5. General Specifications
Mains Supply 3 x 525- 690 VAC
FC 302
High/ Normal Load*
5
Max. input current
* High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s
120
Typical Shaft output at 550
V [kW]
Typical Shaft output at 575
V [HP]
Typical Shaft output at 690
V [kW]
Enclosure IP21
Enclosure IP54
Enclosure IP00
Output current
Continuous
(at 550 V) [A]
Intermittent (60 sec over-
load)
(at 550 V) [A]
Continuous
(at 575/ 690 V) [A]
Intermittent (60 sec over-
load)
(at 575/ 690 V) [A]
Continuous KVA
(at 550 V) [KVA]
Continuous KVA
(at 575 V) [KVA]
Continuous KVA
(at 690 V) [KVA]
Continuous
(at 550 V ) [A]
Continuous
(at 575 V) [A]
Continuous
(at 690 V) [A]
Max. cable size, mains, mo-
tor and load share [mm 2 4x240 (4x500 mcm)
(AWG)]
Max. cable size, brake
[mm 2 (AWG)]
Max. external pre-fuses [A]
1
Estimated power loss
at rated max. load [W] 4)
Weight,
enclosure IP21, IP 54 [kg]
Weight,
enclosure IP00 [kg]
4)
Efficiency
Output frequency
Heatsink overtemp. trip
Power card ambient trip
MG.33.U2.02 - VLT
Operating Instructions High Power
P400 P500
HO NO HO
315 400 400
400 500 500
400 500 500
E1
E1
E2
429 523 523
644 575 785
410 500 500
615 550 750
409 498 498
408 498 498
490 598 598
413 504 504
395 482 482
395 482 482
4x240 (4x500 mcm)
2 x 185 2 x 185
(2 x 350 mcm) (2 x 350 mcm)
700 900
5818 7249 7671
263 272
221 236
0.98
0 - 500 Hz
85 °C
68 °C
® is a registered Danfoss trademark
®
VLT Automation Drive FC 300
P560
NO HO NO
450 450 500
600 600 650
560 560 630
E1 E1
E1 E1
E2 E2
596 596 630
656 894 693
570 570 630
627 855 693
568 568 600
568 568 627
681 681 753
574 574 607
549 549 607
549 549 607
4x240 (4x500 mcm)
2 x 185
(2 x 350 mcm)
900
8727 8715 9673
313
277
