3. How to Install
3
Illustration 3.41: Rectifier Cabinet, enclosure F1, F2, F3 and F4
1)
24 V DC, 5 A
T1 Output Taps
Temp Switch
106 104 105
2)
Manual Motor Starters
3)
30 A Fuse Protected Power Terminals
4)
Line
R
S
T
L1
L2
L3
5)
Loadsharing
-DC +DC
88
89
52
MG.33.U2.02 - VLT
®
is a registered Danfoss trademark
®
VLT
Automation Drive FC 300
Operating Instructions High Power
