Danfoss VLT Automation Drive FC 300 Operating Instructions Manual page 23

®
VLT Automation Drive FC 300
Operating Instructions High Power
Frame size
IP
NEMA
Shipping dimensions Height
Width
Depth
Drive dimensions Height
Width
Depth
Max weight
Mechanical dimensions, E and F Enclosures
Frame size
250 - 400 kW
(380 - 500 V)
355 - 560 kW
(525-690 V)
IP 21, 54
NEMA Type 12
Shipping di- Height
mensions
Width
Depth
Drive dimen-
Height
sions
Width
Depth
Max
weight
Mechanical dimensions , D Enclosures
D1
90 - 110 kW
(380 - 500 V)
37 - 132 kW
(525-690 V)
21 54
Type 1 Type 12
650 mm 650 mm
1730 mm 1730 mm 1730 mm 1730 mm
570 mm 570 mm
1209 mm 1209 mm 1589 mm 1589 mm
420 mm 420 mm
380 mm 380 mm
104 kg 104 kg
E1 E2
250 - 400 kW
(380 - 500 V)
355 - 560 kW
(525-690 V)
00 21, 54
Chassis Type 12
840 mm 831 mm
2197 mm 1705 mm
736 mm 736 mm
2000 mm 1547 mm
600 mm 585 mm
494 mm 498 mm
313 kg 277 kg
MG.33.U2.02 - VLT ® is a registered Danfoss trademark
D2 D3
132 - 200 kW 90 - 110 kW
(380 - 500 V) (380 - 500 V)
160 - 315 kW 37 - 132 kW
(525-690 V) (525-690 V)
21 54 00
Type 1 Type 12 Chassis
650 mm 650 mm 650 mm
1220 mm
570 mm 570 mm 570 mm
1046 mm
420 mm 420 mm 408 mm
380 mm 380 mm 375 mm
151 kg 151 kg 91 kg
F1 F2
450 - 630 kW 710 - 800 kW
(380 - 500 V) (380 - 500 V)
630 - 800 kW 900 - 1000 kW
(525-690 V) (525-690 V)
21, 54
Type 12
2324 mm 2324 mm
1569 mm 1962 mm
927 mm 927 mm
2204 2204
1400 1800
606 606
1004 1246
3. How to Install
D4
132 - 200 kW
(380 - 500 V)
160 - 315 kW
(525-690 V)
00
Chassis
650 mm
1490 mm
570 mm
1327 mm
408 mm
375 mm
138 kg
F3 F4
450 - 630 kW 710 - 800 kW
(380 - 500 V) (380 - 500 V)
630 - 800 kW 900 - 1000 kW
(525-690 V) (525-690 V)
21, 54 21, 54
Type 12 Type 12
2324 mm 2324 mm
2159 mm 2559 mm
927 mm 927 mm
2204 2204
2000 2400
606 606
1299 1541
