VLT Automation Drive FC 300
Operating Instructions High Power
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
Table 3.1: Cable positions as shown in drawings above. Dimensions in mm (inch).
IP 21 (NEMA 1) / IP 54 (NEMA 12)
Enclosure D1 Enclosure D2
277 (10.9) 379 (14.9)
227 (8.9) 326 (12.8)
173 (6.8) 273 (10.8)
179 (7.0) 279 (11.0)
370 (14.6) 370 (14.6)
300 (11.8) 300 (11.8)
222 (8.7) 226 (8.9)
139 (5.4) 142 (5.6)
55 (2.2) 59 (2.3)
354 (13.9) 361 (14.2)
284 (11.2) 277 (10.9)
334 (13.1) 334 (13.1)
250 (9.8) 250 (9.8)
167 (6.6) 167 (6.6)
261 (10.3) 260 (10.3)
170 (6.7) 169 (6.7)
120 (4.7) 120 (4.7)
256 (10.1) 350 (13.8)
308 (12.1) 332 (13.0)
252 (9.9) 262 (10.3)
196 (7.7) 192 (7.6)
260 (10.2) 273 (10.7)
MG.33.U2.02 - VLT ® is a registered Danfoss trademark
IP 00 / Chassis
Enclosure D3 Enclosure D4
119 (4.7) 122 (4.8)
68 (2.7) 68 (2.7)
15 (0.6) 16 (0.6)
20.7 (0.8) 22 (0.8)
363 (14.3) 363 (14.3)
293 (11.5) 293 (11.5)
215 (8.4) 218 (8.6)
131 (5.2) 135 (5.3)
48 (1.9) 51 (2.0)
347 (13.6) 354 (13.9)
277 (10.9) 270 (10.6)
326 (12.8) 326 (12.8)
243 (9.6) 243 (9.6)
159 (6.3) 159 (6.3)
261 (10.3) 261 (10.3)
170 (6.7) 170 (6.7)
120 (4.7) 120 (4.7)
98 (3.8) 93 (3.7)
301 (11.8) 324 (12.8)
245 (9.6) 255 (10.0)
189 (7.4) 185 (7.3)
260 (10.2) 273 (10.7)
3. How to Install
