[DeviceA] display nqa result admin test
NQA entry (admin admin, tag test) test results:
Destination IP address: 10.2.2.2
Send operation times: 1
Min/Max/Average round trip time: 19/19/19
Square-Sum of round trip time: 361
Last succeeded probe time: 2011-01-22 10:40:27.7
Extended results:
Packet loss in test: 0%
Failures due to timeout: 0
Failures due to disconnect: 0
Failures due to no connection: 0
Failures due to sequence error: 0
Failures due to internal error: 0
Failures due to other errors: 0
Packet(s) arrived late: 0
# Display the history of DLSw tests.
[DeviceA] display nqa history admin test
NQA entry (admin admin, tag test) history record(s):
Index
1

NQA collaboration configuration example

Network requirements
As shown in
Associate the static route, track entry, and NQA test group to verify whether static route is active in real
time.
Figure 53 Network diagram
Vlan-int3
10.2.1.1/24
Vlan-int3
10.2.1.2/24
Device A
Configuration procedure
Assign each interface an IP address. (Details not shown)
1.
On Device A, configure a unicast static route and associate the static route with a track entry.
2.
# Configure a static route, whose destination address is 10.2.1.1, and associate the static route with track
entry 1.
<DeviceA> system-view
[DeviceA] ip route-static 10.1.1.2 24 10.2.1.1 track 1
Response Status
19 Succeeded
Figure 53, configure a static route to Device C on Device A, with Device B as the next hop.
Device B
Vlan-int2
10.1.1.1/24
Vlan-int2
10.1.1.2/24
Receive response times: 1
Time
2011-01-22 10:40:27.7
Device C
154
