Min positive SD: 3
Max positive SD: 30
Positive SD number: 186
Positive SD sum: 2602
Positive SD average: 13
Positive SD square sum: 45304
Min negative SD: 1
Max negative SD: 30
Negative SD number: 181
Negative SD sum: 181
Negative SD average: 13
Negative SD square sum: 46994
One way results:
Max SD delay: 46
Min SD delay: 7
Number of SD delay: 410
Sum of SD delay: 3705
Square sum of SD delay: 45987
SD lost packet(s): 0
Lost packet(s) for unknown reason: 0
NOTE:
The display nqa history command does not show the results of UDP jitter tests. To know the result of a UDP
jitter test, use the display nqa result command to view the probe results of the latest NQA test, or use the
display nqa statistics command to view the statistics of NQA tests.

SNMP test configuration example

Network requirements
As shown in
query packet to the SNMP agent and receive a response packet.
Figure 48 Network diagram
Configuration procedure
NOTE:
Before you make the configuration, make sure the devices can reach each other.
Configure the SNMP agent (Device B).
1.
# Enable the SNMP agent service and set the SNMP version to all, the read community to public, and
the write community to private.
<DeviceB> system-view
Figure 48, configure NQA SNMP tests to test the time it takes for Device A to send an SNMP
Min positive DS: 1
Max positive DS: 79
Positive DS number: 158
Positive DS sum: 1928
Positive DS average: 12
Positive DS square sum: 31682
Min negative DS: 1
Max negative DS: 78
Negative DS number: 209
Negative DS sum: 209
Negative DS average: 14
Negative DS square sum: 3030
Max DS delay: 46
Min DS delay: 7
Number of DS delay: 410
Sum of DS delay: 3891
Square sum of DS delay: 49393
DS lost packet(s): 0
