H3C S3100V2-52TP Configuration Manual page 105

Configuring source ports for the remote source group
If you use system view, you can use a list to configure multiple source ports for a mirroring group at one
time. If you use interface view, you can assign only the current port to the group as a source port, so you
must repeat the step for each additional port.
• Configuring source ports in system view
Follow these steps to configure source ports for the remote source group in system view:
To do...
Enter system view
Configure source ports for
the remote source group
Configuring a source port in interface view
•
Follow these steps to configure a source port for the remote source group in interface view:
To do...
Enter system view
Enter interface view
Configure the current port as
a source port
NOTE:
A mirroring group can contain multiple source ports.
•
On the S3100V2-52TP switch, each port, serving as a unidirectional or bidirectional source port, can be
•
added to up to two mirroring groups.
• To make sure that the mirroring function works properly, do not assign a source port to the remote probe
VLAN.
Configuring source CPUs for the remote source group
Follow these steps to configure source CPUs for the remote source group:
To do...
Enter system view
Configure source CPUs
NOTE:
A mirroring group can contain multiple source CPUs.
Configuring the egress port for the remote source group
You can configure the egress port for a mirroring group in system view, or assign the current port to it as
the egress port in interface view. The two configuration modes lead to the same result.
Use the command...
system-view
mirroring-group group-id
mirroring-port mirroring-port-list
{ both | inbound | outbound }
Use the command...
system-view
interface interface-type
interface-number
[ mirroring-group group-id ]
mirroring-port { both | inbound |
outbound }
Use the command...
system-view
mirroring-group group-id
mirroring-cpu slot slot-number-list
{ both | inbound | outbound }
93
Remarks
—
Required
By default, no source port is configured
for a remote source group.
Remarks
—
—
Required
By default, a port does not serve as a
source port for any remote source group.
Remarks
—
Required
By default, no source CPU is
configured for a remote source group.
