NOTE:
A VLAN can serve for only one mirroring group.
•
When a VLAN is configured as a remote probe VLAN, you must remove the remote probe VLAN
•
configuration before deleting the VLAN.
When you remove the configuration of a remote probe VLAN, an active mirroring group becomes
•
inactive.
When a VLAN is configured as a remote probe VLAN, use the remote probe VLAN for port mirroring
•
exclusively. Do not create a VLAN interface for the VLAN or configure any other features for the VLAN.
The remote mirroring groups on the source device and destination device must use the same remote
•
probe VLAN.
Configuring a remote destination group (on the destination
device)
To configure a remote destination group, make the following configurations on the destination device:
Creating a remote destination group
Follow these steps to create a remote destination group:
To do...
Enter system view
Create a remote destination group
Configuring the monitor port for the remote destination group
You can configure the monitor port for a mirroring group in system view, or assign the current port to a
mirroring group as the monitor port in interface view. The two methods lead to the same result.
Configuring the monitor port in system view
•
Follow these steps to configure the monitor port for the remote destination group in system view:
To do...
Enter system view
Configure the monitor port
• Configuring the monitor port in interface view
Follow these steps to configure the monitor port for the remote destination group in interface view:
To do...
Enter system view
Enter interface view
Use the command...
system-view
mirroring-group group-id
remote-destination
Use the command...
system-view
mirroring-group group-id
monitor-port monitor-port-id
Use the command...
system-view
interface interface-type
interface-number
95
Remarks
—
Required
By default, no remote destination
group exists on a device.
Remarks
—
Required
By default, no monitor port is configured
for a remote destination group.
Remarks
—
—
