Configuring the egress port in system view
•
Follow these steps to configure the egress port for the remote source group in system view:
To do...
Enter system view
Configure the egress port for the
remote source group
• Configuring the egress port in interface view
Follow these steps to configure the egress port for the remote source group in interface view:
To do...
Enter system view
Enter interface view
Configure the current port as the
egress port
NOTE:
A mirroring group contains only one egress port.
•
A source port of an existing mirroring group cannot be configured as an egress port.
•
To make sure that the mirroring function works properly, disable these functions on the egress port: the
•
spanning tree feature, 802.1X, IGMP snooping, static ARP, and MAC address learning.
Configuring the remote probe VLAN for the remote source group
Before configuring a remote probe VLAN, create a static VLAN that will serve as the remote probe VLAN
for the remote source group.
Follow these steps to configure the remote probe VLAN for the remote source group:
To do...
Enter system view
Configure the remote
probe VLAN
Use the command...
system-view
mirroring-group group-id
monitor-egress
monitor-egress-port
Use the command...
system-view
interface interface-type
interface-number
mirroring-group group-id
monitor-egress
Use the command...
system-view
mirroring-group group-id
remote-probe vlan
rprobe-vlan-id
94
Remarks
—
Required
By default, no egress port is configured for
a remote source group.
Remarks
—
—
Required
By default, a port does not serve as the
egress port for any remote source group.
Remarks
—
Required
By default, no remote probe VLAN is configured
for a remote source group.
