EQUIPMENT LAYOUT

The purpose of this menu is to allow the operator to manage connections of components and accessories that are part of the
welding plant.
To access the EQUIPMENT LAYOUT Menu from the ADVANCED SETUP Menu:
• Turn the ENCODER K
NOB
• Push the ENTER/MEM K
EY
ENCODER K
Within the EQUIPMENT LAYOUT Menu, it is possible, by rotating the ENCODER K
plant, while by rotating the ENCODER K
ponent (e.g. Torch 400 A H2O) that is to be connected to the plant (this operation does not require confirmation).
Advanced function
WATER COOLER
WATER COOLER OPTIONAL
WIRE FEEDER OPTIONAL
DIGITORCH OPTIONAL
ANALOGIC RC OPTIONAL
TORCH TYPE 400A H2O
SAFETY CALIBRATION CODE 013
WIRE FEEDER
WATER COOLER OPTIONAL
WIRE FEEDER OPTIONAL
DIGITORCH OPTIONAL
ANALOGIC RC OPTIONAL
TORCH TYPE 400A H2O
SAFETY CALIBRATION CODE 013
DIGITORCH
WATER COOLER OPTIONAL
WIRE FEEDER OPTIONAL
DIGITORCH OPTIONAL
ANALOGIC RC OPTIONAL
TORCH TYPE 400A H2O
SAFETY CALIBRATION CODE 013
ANALOGIC RC
WATER COOLER OPTIONAL
WIRE FEEDER OPTIONAL
DIGITORCH OPTIONAL
ANALOGIC RC OPTIONAL
TORCH TYPE 400A H2O
SAFETY CALIBRATION CODE 013
- SX to select the desired icon.
.
MENU K
EY
SX K
EY
- SX
NOB
- DX, you can decide the type of connection required (e.g. Optional) or the type of com-
NOB
OPTIONAL - Means that the water cooler system may or may not be connected to the
welding machine.
OBLIGATORY - Means that it is obligatory for the water cooler system to be connected to
the welding plant.
A error condition is generated when:
• Switching on or at any other time if the welding plant does not detect the presence.
• During normal operation if the water cooler system is disconnected.
OPTIONAL - Means that the wire feeder may or may not be connected to the welding
machine.
OBLIGATORY - Means that it is obligatory for the wire feeder to be connected to the
welding plant.
A error condition is generated when:
• Switching on or at any other time if the welding plant does not detect the presence.
• During normal operation if the wire feeder is disconnected.
OPTIONAL - Means that the DIGITORCH torch may or may not be connected to the
welding machine.
OPTIONAL - Means that the ANALOGIC RC remote control may or may not be
connected to the welding plant.
OBLIGATORY - Means that it is obligatory for the ANALOGIC RC remote control to be
connected to the welding plant.
A error condition is generated when:
• Switching on or at any other time if the welding plant does not detect the presence.
• During normal operation if the ANALOGIC RC remote control is disconnected.
WARNING: For indications on use and functioning of the ANALOGIC RC remote
control see the manuals for the welding machine and the wire feeder, enclosed with the
documentation.
WATER COOLER OPTIONAL
WIRE FEEDER OPTIONAL
DIGITORCH OPTIONAL
ANALOGIC RC OPTIONAL
TORCH TYPE 400A H2O
SAFETY CALIBRATION CODE 013
Description
71
ADVANCED SETUP Menu
ENTER/MEM K
EY
DX K
EY
ENCODER K - DX
NOB
VISION S
CREEN
- SX, to select the component of the welding
NOB
