CEA DIGITECH vision PULSE Series Operator's Manual page 3

- WSC Wire start control. This arc striking control device pre-
vents wire from sticking to the workpiece or torch nozzle
and ensures precise and smooth arc striking, particularly
when welding aluminium.
- Welding parameters that are controlled digitally by a micro-
processor, are monitored and modified in just a few sec-
onds, maintaining a consistently precise and stable arc as
the welding conditions continue to vary due to the move-
ment of the torch and the irregularities of the parts to be
welded.
- Exclusive SWS "Smart Welding Stop" system at the end of
TIG welding. Lifting up the torch without switching off the
arc will introduce a slope down and it will switch off auto-
matically.
- "Energy Saving" function to operate the power source cool-
ing fan and the torch water cooling only when necessary.
- Auto-diagnostic feature for trouble shooting.
- Password-controlled total or partial equipment access.
• High electrical performance resulting in a reduction in ener-
gy consumption.
• Remote parameter adjustment directly from HT4 feeder.
Model
Three-phase input 50/60 Hz
Mains supply: Z
max
Input power @ I Max
2
Delayed fuse (I @ 60%)
2
Power factor / cosφ
Efficiency degree
Open circuit voltage
Current range
Duty cycle @ 100% (40°C)
Duty cycle @ 60% (40°C)
Duty cycle @ X% (40°C)
Wires diameter (*)
N° rollers (*)
Power output of feeder motor (*)
Rated wire feeding speed (*)
Spool (*)
Diameter
Weight
Standards
Protection class
Insulation class
Dimensions
Weight
(*) On the HT4 feeder, fitted separately.
WARNING: This equipment complies with EN//IEC 61000-3-12 provided that the maximum permissible system impedance Z
equal to 0,037 Ω DIGITECH vision PULSE 3300 - 0,028 Ω DIGITECH vision PULSE 4000 - 0,017 Ω DIGITECH vision PULSE 5000 at the in-
terface point between the user's supply and the public system. It is the responsibility of the installer or user of the equipment to ensure, by con-
sultation with the distribution network operator if necessary, that the equipment is connected only to a supply with maximum permissible system
impedance Z less than or equal to 0,037 Ω DIGITECH vision PULSE 3300 - 0,028 Ω DIGITECH vision PULSE 4000 - 0,017 Ω DIGITECH
max
vision PULSE 5000.
This system, tested according to EN/IEC 61000-3-3, meets the requirements of EN/IEC 61000-3-11.
The general technical data of the system are summarized in
table 1.
The use of a welder is typically discontinuous, in that it is made
up of effective work periods (welding) and rest periods (for the
positioning of parts, the replacement of wire and underflush-
ing operations etc. This welder is dimensioned to supply a I
max nominal current in complete safety for a period of work of
40/50% of the total usage time. The regulations in force estab-
lish the total usage time to be 10 minutes. The work cycle is
considered to be 40/50% of this period of time. Exceeding the
work cycle allowed could cause a trip switch to trip (for further
information see the DH control panel manual), which protects
the components inside the welding machine against dangerous
overheating. After several minutes the overheat cut-off rearms
automatically and the welder is ready for use again.
DIGITECH vision PULSE
3300
V 400 ± 20%
Ω 0,037
kVA 18,8
A 25
0,64 / 0,99
η 0,83
V 63
A 10 ÷ 330
A 280
A 300
A 330 (40%)
mm 0,6 ÷ 1,2 (*)
4 (*)
W 100 (*)
m/min 0,5 ÷ 25 (*)
mm Ø300 (*)
kg 15 (*)
IEC 60974-1 - IEC 60974-5 (*) - IEC 60974-10
IP 23 S
H
mm 660 - 515 - 290
kg 35
3
Technical data
Usage limits (IEC 60974-1)
DIGITECH vision PULSE
4000
MIG-MAG welding
400 ± 20%
0,028
25,5
30
0,66 / 0,99
0,86
70
10 ÷ 400
330
370
400 (50%)
0,6 ÷ 1,6 (*)
4 (*)
100 (*)
0,5 ÷ 25 (*)
Ø300 (*)
15 (*)
IP 23 S
H
660 - 515 - 290
40
2
Table 1
DIGITECH vision PULSE
5000
400 ± 20%
0,017
32
40
0,66 / 0,99
0,89
70
10÷500
380
460
500 (50%)
0,6 ÷ 1,6 (*)
4 (*)
100 (*)
0,5 ÷ 25 (*)
Ø300 (*)
15 (*)
IP 23 S
H
660 - 515 - 290
44
is less than or
max
