Operation with the MOVITOOLS
Proceed as follows to configure an SBus connection:
1. Click
11.5.4

Communication parameters for SBus

The following table describes the [Basic setting] for the SBus communication channel:
Communication para-
meter
Baud rate
Communication SBus (CAN) via interface adapter
on "Configure communication
Description
Transmission speed with
which the connected PC
communicates with the
device in the network via
the communication chan-
nel.
Manual – DFS21B PROFINET IO Fieldbus Interface with PROFIsafe
®
MotionStudio engineering software
connections"
Information
• Adjustable values (per-
mitted total cable
length):
– 125 kBaud (500 m)
– 250 kBaud (250 m)
– 500 kBaud (100 m)
– 1 Mbaud (25 m)
• All connected devices
must support the same
baud rate.
11
[1] in the toolbar.
[1]
1166382731
(Default setting)
125
