5. MAINTENANCE

The bulb assembly has the following components:

1. Blue lamp housing

2. Notch indicating the front (light output) side

3. Front terminal (smaller threads)

4. Rear terminal (larger threads)

5. Front (thinner) heat sink

6. Bulb mounting ring

7. Xenon Bulb

8. Rear (thicker) heat sink

9. Heat sink retaining clips
