TURBO-BLANKING IS TURNED OFF, PRESS 1 TO
ENABLE OR 0 TO KEEP IT OFF
Press 1 to activate the option and return to the MAIN MENU or 0 to abort the routine and
return to the MAIN MENU. The status of the TURBO-BLANKING mode will be indicated on
the first line of the MAIN MENU.

3.7.10 Display the First Four Filter Values Mode

[MODE/3]
To display the current Input and Output Galvanometer Values for the first four FILTER
NUMBERS press the MODE key. The following menu will be displayed:
0=EXIT, 1=NEXT PAGE, 2 = TURBO BLANKING
3 = DISPLAY THE FIRST 4 FILTER VALUES
To bring up the values display, press 3.
#1 IN=3800 OUT=1000
#3 IN=1500 OUT=3200
Press ANY key to return to the MAIN MENU.
LAMBDA DG-4 & DG-5 OPERATION MANUAL – REV. 3.05C (20150414)
#2 IN=2500 OUT=2100
#4 IN=1000 OUT=4000
