Included with each system is a set of four slide-in filter holders. If you wish to quickly replace
any installed filter from a set of many filters, you may wish to order additional slide-in filter
holders.

1.2.1 Lambda DG-4 and Lambda DG-5

Throughout this manual, unless otherwise noted, all references and descriptions pertaining
to "Lambda DG-4" (or just "DG-4") apply equally to the Lambda DG-5. The only difference
between the Lambda DG-4 and Lambda DG-5 is the set of light interference filter holders, as
follows:
The Lambda DG-4 filter set consists of four 25mm (1-inch) diameter filter holders.
The Lambda DG-5 filter set consists of three 18mm and two 25mm (1-inch) diameter
filters holders.
Both models of the Lambda DG series are calibrated at the factory according to each one's
filter holder set arrangement.

1.2.2 Systems

The basic DG-4 system consists of the Lambda DG-4 cabinet, lamp bulb, four slide-in filter
holders (25mm), one neutral density filter holder, spanner wrench, liquid light guide, power
cord, serial and parallel cables, and manual. The following list provides more detail of the
system's contents based on model.
A basic DG-5 system is the same as a basic DG-4 system with the exception of having three
18mm filter holders and two 25mm filter holders.
DG-4/OF: Basic DG-4 system with 175-Watt ozone-free xenon arc bulb.
DG-4/OF300: Basic DG-4 system with 300-Watt ozone-free xenon arc bulb.
DG-4/FS: Basic DG-4 system with 175-Watt full spectrum xenon arc bulb.
DG-4/FS300: Basic DG-4 system with 300-Watt full spectrum xenon arc bulb.
DG-5/OF: Basic DG-5 system with 175-Watt ozone-free xenon arc bulb.
DG-5/OF300: Basic DG-5 system with 300-Watt ozone-free xenon arc bulb.
DG-5FS: Basic DG-5 system with 175-Watt full spectrum xenon arc bulb.
DG-5/FS300: Basic DG-5 system with 300-Watt full spectrum xenon arc bulb.
