Byte Value
Dec. Hex. Binary Alt-keypad
entry
208 D0 11010000 Alt-0208
- - -
217 D9 11011001 Alt-0217
218 DA 11011010 Alt-0218
219 DB 11011011 Alt-0219
220 DC 11001100 Alt-0220
- - -
222 DE 11001110 Alt-0222
223 DF 11011111 Alt-0223
224 E0 11100000 Alt-0224
- - -
233 E9 11101001 Alt-0233
234 EA 11101010 Alt-0234
235 EB 11101011 Alt-0235
236 EC 11101100 Alt-0236
237 ED 11101101 Alt-0237
238 EE 11011110 Alt-0238
239 EF 11011111 Alt-0239
240 F0 11110000 Alt-0240
241 F1 11110001 Alt-0241
242 F2 11110010 Alt-0242
243 F3 11110011 Alt-0243
- - -
255 FF 11111111 Alt-0255
NOTE: The "ASCII def./char." column for codes 128 through 255 (80 through FF hex) is left blank, since there
are no ASCII character definitions for the codes in this range. However, many computers and operating systems
do support characters within this range, although there is no single standard across all platforms. Furthermore,
many operating systems, such as Microsoft Windows and Apple Mac OS X, have several "code pages" (character
sets), many of which are country/language specific, from which the user can select. Therefore, this part of the
table is left blank – if you wish, you may write in the characters defined in the character set you use on a regular
basis.
Keyboard Entry
Ctrl- ASCII
char. def./-
char.
-
Freeze display
Turn display on
-
Start loading ring buffer
-
Start the remote adjustment of neutral density setting for current
filter position.
Increase value of Galvo DAC for neutral density setting of current
filter position.
Decrease value of Galvo DAC for neutral density setting of current
filter position.
End the remote adjustment of neutral density setting for current
filter position and save
Set controller to On Line (serial or parallel port); pressing LOCAL
key sets controller to off line).
End loading ring buffer
Run from ring buffer
End run from ring buffer
-
LAMBDA DG-4 & DG-5 OPERATION MANUAL – REV. 3.05C (20150414)
Description
67
