DISCLAIMER

The ultra high speed wavelength switching xenon arc lamp Lambda DG-4/5 system is
designed for the specific use as a microscope illuminator and optical wavelength switcher, and
no other use is recommended.
This instrument should only be used in a laboratory environment for use on animal tissues.
It is not intended for, nor should it be used in, human experimentation or applied to humans
in any way. This is not a medical device.
Do not open or attempt to repair the instrument without expressed and explicit instructions
from Sutter Instrument Company. Extreme heat and high voltages are present and could
cause injury.
Do not allow unauthorized and or untrained operatives to use this device.
Any misuse will be the sole responsibility of the user/owner and Sutter Instruments assumes
no implied or inferred liability for direct or consequential damages from this instrument if it
is operated or used in any way other than for which it is designed.

SAFETY WARNINGS AND PRECAUTIONS

Electrical

Operate the Lambda DG-4/5 using 110-120 V AC, 60 Hz, or 220-240 V AC., 50 Hz line
voltage. This instrument is designed for connection to a standard laboratory power outlet
(Overvoltage Category II), and because it is a microprocessor--controlled device, it should
be accorded the same system wiring precautions as any 'computer type' system. A surge
protector and power regulator are recommended.
Fuse Replacement: Replace only with the same type and rating:
5 x 20 mm glass tube, time delay (medium), time lag, or "slow blow")
Rating:
Xenon
Line Voltage: 100 - 120VAC
Lamp
(Voltage Switch Setting: 110V)
Power
Fuse
Rating
Rating
RoHS Compliant (Lead Free)?
125 3.0A,
Bussmann: GMC-3-R
1
Watts 125V
Littelfuse: 239 003.P
175 4.0A,
Bussmann: GMC-4-R
Watts 125V
Littelfuse: 239 004.P
300 5.0A,
Bussmann: GMC-5-R
Watts 125V
Littelfuse: 239 005.P
A spare fuse is located in the power input module. Please refer to the fuse-replacement
appendix for more details on fuse ratings and for instructions on how to change the fuse.
1
NOTE: The 125-Watt lamp version of the DG-4/DG-5 is a discontinued product.
Manufacturer Examples
Yes No
Bussmann: GMC-3A
Littelfuse: 239 003
Bussmann: GMC-4A
Littelfuse: 239 004
Bussmann: GMC-5A
Littelfuse: 239 005
LAMBDA DG-4 & DG-5 OPERATION MANUAL – REV. 3.05C (20150414)
Line Voltage: 220 - 240VAC
(Voltage Switch Setting: 220V)
Fuse Manufacturer Examples
Rating
RoHS Compliant (Lead Free)?
Yes
T2.0A,
Bussmann: S506-2-R
250V
Littelfuse: 218 002.P
T3.15A,
Bussmann: S506-315-R
250V
Littelfuse: 218 3.15P
iii
No
Bussmann: GDC-2A
Littelfuse: 218 002
Bussmann: GDC-3.15A
Littelfuse: 218 3.15
