TableC-1. Mains fuse requirements according to lamp power ratings and line voltage.
Xenon
Line Voltage: 100 - 120VAC
Lamp
(Voltage Switch Setting: 110V)
Power
Fuse
Rating
Rating
RoHS Compliant (Lead Free)?
125
3.0A,
Bussmann: GMC-3-R
Watts
1
125V
Littelfuse: 239 003.P
175
4.0A,
Bussmann: GMC-4-R
Watts
125V
Littelfuse: 239 004.P
300
5.0A,
Bussmann: GMC-5-R
Watts
125V
Littelfuse: 239 005.P
1
NOTE: The 125-Watt lamp version of the DG-4/DG-5 is a discontinued product.
Manufacturer Examples
Yes
No
Bussmann: GMC-3A
Littelfuse: 239 003
Bussmann: GMC-4A
Littelfuse: 239 004
Bussmann: GMC-5A
Littelfuse: 239 005
LAMBDA DG-4 & DG-5 OPERATION MANUAL – REV. 3.05C (20150414)
Line Voltage: 220 - 240VAC
(Voltage Switch Setting: 220V)
Fuse
Manufacturer Examples
Rating
RoHS Compliant (Lead Free)?
Yes
T2.0A,
Bussmann: S506-2-R
250V
Littelfuse: 218 002.P
T3.15A,
Bussmann: S506-315-R
250V
Littelfuse: 218 3.15P
No
Bussmann: GDC-2A
Littelfuse: 218 002
Bussmann: GDC-3.15A
Littelfuse: 218 3.15
