64
Electrical:
Mains voltage
Power consumption
Power cord
Mains fuse (rear of cabinet)
Cables
Type
Parallel DB-25
Serial DB-9
(RS-232)
Note 1: Fair-Rite Products Corp., P.O. Box J, One Commercial Row, Wallkill, NY, 12589 USA
Note 2: The supplied 9-pin serial RS-232 cable is a "straight-through" cable (Pin 1 of one end wired
to Pin 1 of the other, Pin 2 to Pin 2, etc.). Do not substitute the provided cable with a "null-modem"
cable, or any cable that has Pins 2 and 3 crossed and/or connected to other non-corresponding pins.

Table D-1. Cable specifications.

Max. Length Ferrite at
Controller End
6 ft Fair-Rite
(1.829 m) #0443164-251
(See Note 1)
10 ft Fair-Rite
(3.048 m) #0443167-251
(See Note 1)
LAMBDA DG-4 & DG-5 OPERATION MANUAL – REV. 3.05C (20150414)
110/220 V , 50/60 Hz
756 W
10A, 250V , with safety ground plug
Time delay (or time lag) 5 x 20 mm glass tube.
For specific fuse ratings, refer to APPENDIX C
(FUSE REPLACEMENT)
Dielectric separation of circuits. Foil
shielding
Connected to metal faceplates of
connectors on both ends. (See Note 2.)
Cabling
