20
The numeric key 8 is then pressed to call for FILTER NUMBER = 8.
80 = FILTER NUMBER,
INPUT = MANUAL
When the ENTER key is then pressed, FILTER NUMBER 8 is then displayed correctly.
8 = FILTER NUMBER,
INPUT = MANUAL
Method 2: The main menu will look like this if the initial FILTER NUMBER = 10
10 = FILTER NUMBER,
INPUT = MANUAL
The numeric key 0 is pressed first.
00 = FILTER NUMBER,
INPUT = MANUAL
The numeric key 8 is pressed next with no further action required. FILTER NUMBER 8 is
then displayed correctly.
8 = FILTER NUMBER,
INPUT = MANUAL

3.7.4 Move on Sync Pulse Mode

[MODE/4]
If the Move on Sync Pulse Mode is active, the controller will advance to the next filter in a
previously programmed FILTER NUMBER sequence (Ring Buffer) when an internal video
synchronization (sync) circuit detects the vertical sync pulse of a composite video signal
applied to the SYNC input on the rear of the Lambda DG-4/5. In this way, filter changes can
be coordinated to occur with the capture of video "frames". The FILTER NUMBER sequence
can be programmed at your convenience and then executed later with precise timing (see
SET UP THE RING BUFFER). The FILTER NUMBERS can also be sent individually via the
serial or parallel port before the trigger event. This operational mode is selected by pressing
the MODE key followed by the 4 key to get to the MOVE ON SYNC PULSE menu.
Alternatively, you can "page" through the mode selection menus by pressing MODE followed
by the 1 key. The following menu will be displayed:
LAMBDA DG-4 & DG-5 OPERATION MANUAL – REV. 3.05C (20150414)
TURBO-BLANKING- OFF
MOVE ON COMMAND
TURBO-BLANKING- OFF
MOVE ON COMMAND
TURBO-BLANKING- OFF
MOVE ON COMMAND
TURBO-BLANKING- OFF
MOVE ON COMMAND
TURBO-BLANKING- OFF
MOVE ON COMMAND
