Introduction

1 Introduction

1.1 Purpose of the Quick Guide

The quick guide provides information for safe installation
and commissioning of the adjustable frequency drive.
The quick guide is intended for use by qualified personnel.
Read and follow the quick guide to use the adjustable
frequency drive safely and professionally, and pay
particular attention to the safety instructions and general
warnings. Keep this quick guide available with the
adjustable frequency drive at all times.
®
VLT is a registered trademark.

1.2 Additional Resources

•
®
VLT HVAC Basic Drive FC 101 Programming Guide
provides information on how to program and
includes complete parameter descriptions.
•
®
VLT HVAC Basic Drive FC 101 Design Guide
provides all of the technical information about
the adjustable frequency drive and customer
design and applications. It also lists options and
accessories.
The technical documentation is available in electronic form
on the documentation CD that is shipped with the
product, or in print at the local Danfoss sales office.
MCT 10 Set-up Software Support
Download the software from http://www.danfoss.com/
BusinessAreas/DrivesSolutions/Software+MCT10/
MCT10+Downloads.htm.
During the installation process of the software, enter
access code 81463800 to activate FC 101 functionality. A
license key is not required for using FC 101 functionality.
The latest software does not always contain the latest
drive updates. Contact the local sales office for the latest
drive updates (*.upd files), or download the drive updates
from www.danfoss.com/BusinessAreas/DrivesSolutions/
fc101driveupdates.

1.3 Document and Software Version

The Quick Guide is regularly reviewed and updated. All
suggestions for improvement are welcome.
Edition Remarks
MG18A6xx Replaces MG18A5xx
MG18A622
Quick Guide

1.4 Certificates and Approvals

Certification
EC Declaration of
Conformity
UL-listed
C-tick
Table 1.1 Certificates and Approvals
The adjustable frequency drive complies with UL508C
thermal memory retention requirements. For more
information, refer to the section Motor Thermal Protection
in the product specific design guide.

1.5 Disposal

Software version
2.70
Danfoss A/S © 08/2014 All rights reserved.
IP20
✓
✓
✓
Equipment containing electrical components
may not be disposed of together with domestic
waste.
It must be separately collected with electrical
and electronic waste according to local and
currently valid legislation.
