Power [kW (HP)]
18.5 (25)
22 (30)
30 (40)
37 (50)
45 (60)
55 (70)
75 (100)
90 (125)
3x380–480 V IP54
0.75 (1)
1.5 (2)
2.2 (3)
3 (4)
4 (5)
5.5 (7.5)
7.5 (10)
11 (15)
15 (20)
18.5 (25)
22 (30)
30 (40)
37 (50)
45 (60)
55 (70)
75 (100)
90 (125)
Table 3.8 Circuit Breakers and Fuses
20
VLT®HVAC Basic Drive FC 101
Circuit breaker
UL Non-UL
Cutler-Hammer Cutler-Hammer
EGE3080FFG EGE3080FFG
Cutler-Hammer Cutler-Hammer
JGE3125FFG JGE3125FFG
Cutler-Hammer
Cutler-Hammer
JGE3200FAG
JGE3200FAG
PKZM0-16
PKZM0-16
PKZM0-16
PKZM0-16
PKZM0-16
PKZM0-25
PKZM0-25
PKZM4-63
PKZM4-63
PKZM4-63
Moeller NZMB1-A125
Moeller NZMB2-A160
Moeller NZMB2-A250
Danfoss A/S © 08/2014 All rights reserved.
Fuse
UL
Bussmann Bussmann Bussmann
Type RK5 Type RK1 Type J
FRS-R-80 KTN-R80 JKS-80
FRS-R-80 KTN-R80 JKS-80
FRS-R-80 KTN-R80 JKS-80
FRS-R-125 KTN-R125 JKS-125
FRS-R-125 KTN-R125 JKS-125
FRS-R-125 KTN-R125 JKS-125
JKS-200
FRS-R-200 KTN-R200
FRS-R-200 KTN-R200 JKS-200
FRS-R-10 KTS-R-10 JKS-10
FRS-R-10 KTS-R-10 JKS-10
FRS-R-15 KTS-R-15 JKS-15
FRS-R-15 KTS-R-15 JKS-15
FRS-R-15 KTS-R-15 JKS-15
FRS-R-25 KTS-R-25 JKS-25
FRS-R-25 KTS-R-25 JKS-25
FRS-R-50 KTS-R-50 JKS-50
FRS-R-50 KTS-R-50 JKS-50
FRS-R-80 KTS-R-80 JKS-80
FRS-R-80 KTS-R-80 JKS-80
FRS-R-125 KTS-R-125 JKS-125
FRS-R-125 KTS-R-125 JKS-125
FRS-R-125 KTS-R-125 JKS-125
FRS-R-200 KTS-R-200 JKS-200
FRS-R-200 KTS-R-200 JKS-200
FRS-R-250 KTS-R-250 JKS-200
Non-UL
Maximum
Bussmann
fuse
Type T Type G
JJS-80 80
JJS-80 80
JJS-80 80
JJS-125 125
JJS-125 125
JJS-125 125
JJS-200
200
JJS-200 200
JJS-10 16
JJS-10 16
JJS-15 16
JJS-15 16
JJS-15 16
JJS-25 25
JJS-25 25
JJS-50 63
JJS-50 63
JJS-80 63
JJS-80 125
JJS-125 125
JJS-125 125
JJS-125 160
JJS-200 160
JJS-200 200
JJS-200 200
MG18A622
