Installation; Mechanical Installation; Side-By-Side Installation - Danfoss VLT HVAC Basic Drive FC 101 Quick Manual

Installation

3 Installation
3 3

3.1 Mechanical Installation

3.1.1 Side-by-Side Installation

The adjustable frequency drive can be mounted side-by-side but requires the clearance above and below for cooling.
Frame
H1
H2
H3
H4
H5
H6
H7
H8
H9
H10
I2
I3
I4
I6
I7
I8
Table 3.1 Clearance Required for Cooling
NOTICE!
With IP21/NEMA Type1 option kit mounted, a distance of 50 mm (2 in) between the units is required.
6
IP class 3x200-240 V
IP20 0.25-1.5 (0.33-2)
IP20 2.2 (3)
IP20 3.7 (5)
IP20 5.5-7.5 (7.5-10)
IP20 11 (15)
IP20 15-18.5 (20-25)
IP20 22-30 (30-40)
IP20 37-45 (50-60)
IP20 –
IP20 –
IP54 –
IP54 –
IP54 –
IP54 –
IP54 –
IP54 –
Danfoss A/S © 08/2014 All rights reserved.
VLT®HVAC Basic Drive FC 101
Power [kW (HP)]
3x380-480 V
0.37-1.5 (0.5-2)
2.2-4 (3-5)
5.5-7.5 (7.5-10)
11-15 (15-20)
18.5-22 (25-30)
30-45 (40-60)
55-75 (70-100)
90 (125) 75-90 (100-125)
–
–
0.75-4.0 (1-5)
5.5-7.5 (7.5-10)
11-18.5 (15-25)
22-37 (30-50)
45-55 (60-70)
75-90 (100-125)
Clearance above/below [mm (in)]
3x525-600 V
–
–
–
–
–
18.5-30 (25-40)
37-55 (50-70)
2.2-7.5 (3-10)
11-15 (15-20)
–
–
–
–
–
–
100 (4)
100 (4)
100 (4)
100 (4)
100 (4)
200 (7.9)
200 (7.9)
225 (8.9)
100 (4)
200 (7.9)
100 (4)
100 (4)
100 (4)
200 (7.9)
200 (7.9)
225 (8.9)
MG18A622
