Programming
Motor set-up
The Motor Set-up wizard guides through the needed motor parameters.
Parameter
0-03 Regional Settings
0-06 GridType
4 4
1-10 Motor Construction
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-30 Stator Resistance (Rs)
1-37 d-axis Inductance (Ld)
1-38 q-axis Inductance (Lq)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-42 Motor Cable Length
1-44 d-axis Inductance Sat.
(LdSat)
38
VLT®HVAC Basic Drive FC 101
Range
[0] International
[1] US
[0] -[132] see start-up wizard for
open-loop application
*[0] Asynchron
[1] PM, non-salient SPM
[2] PM, salient IPM, non Sat.
[3] PM, salient IPM, Sat.
0.12–110 kW/0.16–150 HP
50–1000 V
20–400 Hz
0.01–10000.00 A
50–9999 RPM
0.1–1000.0 Nm
0–99.990 Ohm
0–1000 mH
0–1000 mH
2–100
10–9000 V
0–100 m (0–330 ft)
0–1000 mH
Danfoss A/S © 08/2014 All rights reserved.
Default Usage
0 –
Size selected Select the operating mode for restart
upon reconnection of the drive to AC
line voltage after power-down.
[0] Asynchron –
Size related Enter the motor power from the
nameplate data.
Size related Enter the motor voltage from the
nameplate data.
Size related Enter the motor frequency from the
nameplate data.
Size related Enter the motor current from the
nameplate data.
Size related Enter the motor nominal speed from
the nameplate data.
Size related This parameter is available when
1-10 Motor Construction is set to
options that enable permanent motor
mode.
NOTICE!
Changing this parameter affects
the settings of other parameters.
Size related Set the stator resistance value.
Size related Enter the value of the d-axis
inductance.
Obtain the value from the permanent
magnet motor data sheet. The de-axis
inductance cannot be found by
performing an AMA.
Size related Enter the value of the q-axis
inductance.
4 Enter the number of motor poles.
Size related Line-Line RMS back EMF voltage at
1000 RPM.
50 m (164 ft) Enter the motor cable length.
Size related This parameter corresponds to the
inductance saturation of Ld. Ideally,
this parameter has the same value as
1-37 d-axis Inductance (Ld). However, if
the motor supplier provides an
induction curve, the induction value @
200% of isNom should be entered
here.
