3X525-600 V Ac; Mg18A622 Danfoss A/S © 08/2014 All Rights Reserved - Danfoss VLT HVAC Basic Drive FC 101 Quick Manual

Specifications
6.1.3 3x525–600 V AC
Adjustable frequency drive
Typical shaft output [kW]
Typical shaft output [HP]
IP20 frame
Maximum cable size in 4 (10) 4 (10) 4 (10) 4 (10) 4 (10) 10 (8) 10 (8) 35 (2)
terminals (line power, motor)
2
[mm (AWG)]
Output current - 40 °C (104 ° F) ambient temperature
Continuous (3x525–550 V) [A]
Intermittent (3x525–550 V) [A]
Continuous (3x551–600 V) [A]
Intermittent (3x551–600 V) [A]
Maximum input current
Continuous (3x525–550 V) [A]
Intermittent (3x525–550 V) [A]
Continuous (3x551–600 V) [A]
Intermittent (3x551–600 V) [A]
Maximum electrical fuses
Estimated power loss [W],
best case/typical 1)
Weight enclosure IP54 [kg
(lb)]
Efficiency [%],
best case/typical 2)
Output current - 50 °C (122 °F) ambient temperature
Continuous (3x525–550 V) [A]
Intermittent (3x525–550 V) [A]
Continuous (3x551–600 V) [A]
Intermittent (3x551–600 V) [A]
Table 6.6 3x525–600 V AC, 2.2–90 kW (3–125 HP), Enclosure Type H6–H10
1) Applies for dimensioning of adjustable frequency drive cooling. If the switching frequency is higher than the default setting, the power losses
may increase. LCP and typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to
www.danfoss.com/vltenergyefficiency.
2) Efficiency measured at nominal current. For energy efficiency class, see chapter 6.4.13 Ambient Conditions. For part load losses, see
www.danfoss.com/vltenergyefficiency.
MG18A622
Quick Guide
P2K2 P3K0 P3K7 P5K5 P7K5 P11K P15K P18K P22K P30K P37K P45K P55K P75K P90K
2.2 3.0 3.7 5.5 7.5
3.0 4.0 5.0 7.5 10.0
H9 H9 H9 H9 H9
4.1 5.2 6.4 9.5 11.5
4.5 5.7 7.0 10.5 12.7
3.9 4.9 6.1 9.0 11.0
4.3 5.4 6.7 9.9 12.1
3.7 5.1 5.0 8.7 11.9
4.1 5.6 6.5 9.6 13.1
3.5 4.8 5.6 8.3 11.4
3.9 5.3 6.2 9.2 12.5
See chapter 3.2.4 Fuses and Circuit Breakers
65 90 110 132 180
6.6 6.6 6.6 6.6 6.6
(14.6) (14.6) (14.6) (14.6) (14.6)
97.9 97 97.9 98.1 98.1
2.9 3.6 4.5 6.7 8.1
3.2 4.0 4.9 7.4 8.9
2.7 3.4 4.3 6.3 7.7
3.0 3.7 4.7 6.9 8.5
