Danfoss VLT HVAC Basic Drive FC 101 Quick Manual page 32

Programming
Parameter
1-10 Motor Construction
4 4
1-20 Motor Power
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
30
VLT®HVAC Basic Drive FC 101
Option
*[0] Asynchron
[1] PM, non-salient SPM
[2] PM, salient IPM, non
Sat.
[3] PM, salient IPM, Sat.
0.12–110 kW/0.16–150
HP
50.0–1000.0 V
20.0–400.0 Hz
0.01–10000.00 A
50.0–9999.0 RPM
Danfoss A/S © 08/2014 All rights reserved.
Default Usage
[0] Asynchron Setting the parameter value might
change these parameters:
1-01 Motor Control Principle
1-03 Torque Characteristics
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
1-17 Voltage filter time const.
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-30 Stator Resistance (Rs)
1-33 Stator Leakage Reactance (X1)
1-35 Main Reactance (Xh)
1-37 d-axis Inductance (Ld)
1-38 q-axis Inductance (Lq)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-44 d-axis Inductance Sat. (LdSat)
1-45 q-axis Inductance Sat. (LqSat)
1-46 Position Detection Gain
1-48 Current at Min Inductance for
d-axis
1-49 Current at Min Inductance for
q-axis
1-66 Min. Current at Low Speed
1-70 PM Start Mode
1-72 Start Function
1-73 Flying Start
4-14 Motor Speed High Limit [Hz]
4-19 Max Output Frequency
4-58 Missing Motor Phase Function
14-65 Speed Derate Dead Time
Compensation
Size related Enter the motor power from the
nameplate data.
Size related Enter the motor voltage from the
nameplate data.
Size related Enter the motor frequency from
the nameplate data.
Size related Enter the motor current from the
nameplate data.
Size related Enter the motor nominal speed
from the nameplate data.
MG18A622
