Installation
I4 enclosure
3 3
1 RS-485
2 Line power
3 Ground
4 Cable clamps
5 Motor
6 UDC
7 Relays
8 I/O
Figure 3.15 I4 Enclosure
IP54, 380-480 V, 0.75-4.0 kW (1-5 HP)
16
VLT®HVAC Basic Drive FC 101
Figure 3.16 IP54 I2-I3-I4 Enclosure
I6 enclosure
Figure 3.17 Connecting to Line Power for I6 Enclosure
IP54, 380-480 V, 22-37 kW (30-50 HP)
