Digital Inputs; Analog Inputs; Analog Output; Digital Output - Danfoss VLT HVAC Basic Drive FC 101 Quick Manual

Specifications

6.4.5 Digital Inputs

Programmable digital inputs
Terminal number
Logic
Voltage level
Voltage level, logic 0 PNP
Voltage level, logic 1 PNP
Voltage level, logic 0 NPN
Voltage level, logic 1 NPN
Maximum voltage on input
Input resistance, R
Digital input 29 as thermistor input
6 6
Digital input 29 as Pulse input

6.4.6 Analog Inputs

Number of analog inputs
Terminal number
Terminal 53 mode
Terminal 54 mode
Voltage level
Input resistance, R
Maximum voltage
Current level
Input resistance, R
Maximum current
Resolution on analog input

6.4.7 Analog Output

Number of programmable analog outputs
Terminal number
Current range at analog output
Maximum load to common at analog output
Maximum voltage at analog output
Accuracy on analog output
Resolution on analog output
1) Terminal 42 and 45 can also be programmed as digital outputs.

6.4.8 Digital Output

Number of digital outputs
Terminal number
Voltage level at digital output
Maximum output current at digital output
Maximum load at digital output
1) Terminals 42 and 45 can also be programmed as analog output.
56
VLT®HVAC Basic Drive FC 101
i
i
i
Danfoss A/S © 08/2014 All rights reserved.
Fault: >2.9 kΩ and no fault: <800 Ω
Maximum frequency 32 kHz push-pull-driven & 5 kHz (O.C.)
Parameter 6-19: 1=voltage, 0=current
Parameter 6-29: 1=voltage, 0=current
Maximum error: 0.4% of full scale
4
18, 19, 27, 29
PNP or NPN
0–24 V DC
<5 V DC
>10 V DC
>19 V DC
<14 V DC
28 V DC
Approximately 4 kΩ
2
53, 54
0–10 V
approximately 10 kΩ
20 V
0/4 to 20 mA (scalable)
<500 Ω
29 mA
10 bit
2
1)
42, 45
0/4–20 mA
500 Ω
17 V
10 bit
2
1)
42, 45
17 V
20 mA
1 kΩ
MG18A622
