Mounting the Intercom
93
Network Cable Entry Restrictions
A.4 Network Cable Entry Restrictions
A.4.1 Conduit Mounting Restrictions (Side Entry)
See
Figure A-4
for the conduit mounting restrictions (side entry).
Figure A-4. Conduit Mounting Restrictions (Side Entry)
Hole Plug
Assembly
5/32"
Gap
Spacer
1/2" Set Screw
Connector
(Not Provided)
1/2" Conduit
(Not Provided)
Network
Cable
(Not Provided)
Operations Guide
931544D
CyberData Corporation
