CyberData 011186 Operation Manual page 42

Web Page Item
Enable DTMF Push to Talk
Prevent Call Termination
Disable HTTPS (NOT recommended)
Operations Guide
Table 2-7. Device Configuration Parameters (continued)
Description
This option is for noisy environments. When enabled, in an active call, the
remote phone can force receive only audio (setting the mic gain to max
and muting the speaker) by pressing the * key.
Pressing the # key will force send only audio (setting the max speaker
volume and muting the mic). Pressing the 0 key will restore full duplex
operation with the normal microphone and speaker volume.
When this option is enabled, a call cannot be terminated using the call
button.
Disables the encrypted connection to the webpage. We do not
recommend disabling HTTPS for security reasons.
Note
Click on the Test Audio button to do an audio test. When the Test Audio
button is pressed, you will hear a voice message for testing the device
audio quality and volume.
Click on the Test Microphone button to do a microphone test. When the
Test Microphone button is pressed, the following occurs:
1. The device will immediately start recording 3 seconds of audio.
2. The device will beep (indicating the end of recording).
3. The device will play back the recorded audio.
Click on the Test Relay button to do a relay test.
Click the Save button to save your configuration settings.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some of the
web page items. First click on the Toggle Help button, and you will see a
question mark (
mouse pointer to hover over a question mark to see a short description of
a specific web page item.
931544D
This setting requires a reboot for the changes to take effect.
) appear next to some of the web page items. Move the
Installing the SIP Outdoor Intercom
Intercom Setup
CyberData Corporation
35
