Connector
J1
J4
JAEC
JCON
JIO
JP5
JX
SW1
a.Do not install a jumper. Momentary short to reset. Permanent installation of a jumper would
prevent the board from running all together.
Operations Guide
Table 2-3. Connector Functions—Board Bottom
Function
PoE Network Connection (RJ-45 ethernet)
SD Card Slot
AEC Configuration Interface (Factory Use Only)
Console Port (Factory Use Only)
Terminal Block (see Figure
a
Reset jumper
Auxiliary Strobe Connector
See Section 2.3.6, "RTFM Button"
931544D
Installing the SIP Outdoor Intercom
2-2)
