2.4.7.2 Point-to-Point Configuration
When the device is set to not register with a SIP server (see
device to dial out to a single endpoint.
In this case, the dial-out extension should be the IP address of the remote device. The device can
also receive Point-to-Point calls. The delayed DTMF functionality is available in the Point-to-Point
Mode.
Note
CyberData Outdoor Intercom
Device is set to NOT register with a SIP server
2.4.7.3 Delayed DTMF
On the SIP Configuration page the dial out extension supports the addition of comma delimited
pauses and sending additional DTMF tones (using rfc2833). The first comma will pause three
seconds after a call is first established with a remote device. Subsequent commas will pause for 2
seconds. A pause of one second will be sent after each numerical digit.
Extension String
302
302,2
302,25,,,4,,1
Note
Operations Guide
Receiving point-to-point SiP calls may not work with all phones.
Figure 2-22. SIP Page Set to Point-to-Point Mode
Table 2-11. Examples of Dial-Out Extension Strings
Resulting Action
Dial out extension 302 and establish a call
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2'
Dial out extension 302 and establish a call, wait 3 seconds then send the
DTMF tone '2', send out DTMF tone 5, wait 6 seconds, send out DTMF
tone 4, wait 4 seconds, send out DTMF tone 1
The maximum number of total characters in the dial-out field is 25.
931544D
Installing the SIP Outdoor Intercom
Figure 2-22), it is possible to set the
