2. On the Multicast page, enter values for the parameters indicated in
Note
Web Page Item
Enable Multicast Operation
Priority
Address
Port
Name
Beep
Relay
Polycom Default Channel
Polycom Priority Channel
Polycom Emergency Channel
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-13. Multicast Page Parameters
Description
Enables or disables multicast operation.
Indicates the priority for the multicast group. Priority 9 is the highest (emergency
streams). 0 is the lowest (background music). SIP calls are considered priority 4.5.
See Section 2.4.9.1, "Assigning Priority"
Enter the multicast IP Address for this multicast group (15 character limit).
Enter the port number for this multicast group (5 character limit [range can be from
2000 to 65535]).
Note: The multicast ports have to be even values. The webpage will enforce this
restriction.
Assign a descriptive name for this multicast group (25 character limit).
When selected, the device will play a beep before multicast audio is sent.
When selected, the device will activate a relay before multicast audio is sent.
When a default Polycom channel/group number is selected, the device will
subscribe to the default channel for one-way group pages. Group Numbers 1-25
are supported. Or, select Disabled to disable this channel.
When a priority Polycom channel/group number is selected, the device will
subscribe to the priority channel for one-way group pages. Group Numbers 1-25
are supported. Or, select Disabled to disable this channel.
When an emergency Polycom channel/group number is selected, the device will
subscribe to the default channel for one-way group pages. Group Numbers 1-25
are supported. Or, select Disabled to disable this channel.
Click the Save button to save your configuration settings.
Click on the Reboot button to reboot the system.
931544D
) in the following table shows which web page items will be defined
.
for more details.
Installing the SIP Outdoor Intercom
Intercom Setup
Table 2-13.
