2. On the Device page, you may enter values for the parameters indicated in
Note
Web Page Item
Volume Settings (0-9)
SIP Volume
Multicast Volume
Ring Volume
Sensor Volume
Push to Talk Volume
Microphone Settings
Microphone Gain
Push to Talk Microphone Gain
Clock Settings
Enable NTP
NTP Server
Timezone
Current Time
Relay Settings
Activate Relay with DTMF Code
Relay Pulse Code
Operations Guide
The question mark icon (
after the Toggle Help button is pressed
Table 2-7. Device Configuration Parameters
Description
Set the speaker volume for a SIP call. A value of 0 will mute the speaker
during SIP calls.
Set the speaker volume for multicast audio streams. A value of 0 will mute
the speaker during multicasts.
Set the ring volume for incoming calls. A value of 0 will mute the speaker
instead of playing the ring tone when Auto-Answer Incoming Calls is
disabled.
Set the speaker volume for playing sensor activated audio. A value of 0
will mute the speaker during sensor activated audio.
Set the speaker volume for Push to Talk operation. A value of 0 will mute
the speaker in Push to Talk mode.
Set the microphone gain level.
Set the microphone gain level for Push to Talk operation.
Sync device's local time with the specified NTP Server.
Use this field to set the address (in IPv4 dotted decimal notation or as a
canonical name) for the NTP Server. This field can accept canonical
names of up to 64 characters in length.
Enter the tz database string of your timezone.
Examples:
America/Los_Angeles
America/New_York
Europe/London
America/Toronto
See
for a full list of valid strings.
Displays the current time.
Activates the relay when the DTMF Activation Code is entered on the
phone during a SIP call with the device. RFC2833 DTMF payload types
are supported.
DTMF code used to pulse the relay when entered on a phone during a
SIP call with the device. Relay will activate for Relay Pulse Duration
seconds then deactivate. Activate Relay with DTMF Code must be
enabled. Enter up to 25 digits (* and # are supported).
931544D
) in the following table shows which web page items will be defined
.
https://en.wikipedia.org/wiki/List_of_tz_database_time_zones
Installing the SIP Outdoor Intercom
Intercom Setup
Table 2-7.
