CyberData 011186 Operation Manual page 49

Web Page Item
SIP Auth Password
Re-registration Interval (in seconds)
Dial Out Settings
Dial Out Extension
Extension ID
Send Multicast Audio
Multicast Address
Multicast Port
Repeat Message
Call Disconnection
Terminate Call After Delay
Audio Codec Selection
Codec
RTP Settings
RTP Port (even)
Jitter Buffer
Note
Operations Guide
Table 2-9. SIP Configuration Parameters (continued)
Description
Specify the Authenticate Password for the SIP Server. This parameter is required for
SIP registration authentication. Enter up to 64 alphanumeric characters.
The SIP Re-registration Interval (in seconds) is the SIP Registration lease time, also
known as the expiry. The supported range is 30-3600 seconds. Enter up to 4 digits.
Specify the extension the device will call when someone presses the Call button.
Enter up to 64 alphanumeric characters.
Note: For information about dial-out extension strings and DTMF tones, see
2.4.7.1, "Dial Out Extension Strings and DTMF Tones (using
A Caller identification string added to outbound calls. Enter up to 64 alphanumeric
characters.
When selected, the device will play an audio file to the specified multicast address
and port.
The multicast address used for multicasting an audio file.
The multicast port used for multicasting an audio file.
The number of times to repeat the audio message to the remote endpoint. Enter a
value from 1-65536.
Automatically terminate an active call after a given delay in seconds. A value of 0
will disable this function. Enter up to 8 digits.
Select the desired codec (only one may be chosen).
Specify the port number used for the RTP stream after establishing a SIP call. This
port number must be an even number and defaults to 10500. The supported range
is 0-65536. Enter up to 5 digits.
Specify the size of the jitter buffer (in milliseconds) used for SIP calls. Valid values
are 50-1000.
Click the Save button to save your configuration settings.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of some of the web page
items. First click on the Toggle Help button, and you will see a question mark (
appear next to some of the web page items. Move the mouse pointer to hover over a
question mark to see a short description of a specific web page item.
For specific server configurations, go to the following website address:
https://www.cyberdata.net/pages/connecting-to-ip-pbx-servers
931544D
Installing the SIP Outdoor Intercom
Intercom Setup
Section
rfc2833)".
