Mounting the Intercom

Dimensions

Figure A-3. Shroud Dimensions—Front and Side View with Mounting Hole Locations

3.434 [87.23]

5.276 [134.00]

ø0.280 [ø7.11]

(4 PLACES)

ø0.854 [ø21.69]

1.690 [42.93]

3.380 [85.85]

0.948 [24.07]

Dimensions are in Inches [Millimeter]
