Summary of Product elements
EX9-OET1, EX9-OET2 (Output block for low wattage load)
Element
Indicator LED
Solenoid valve connector
Output connector (No.0)
Output connector (No.1)
SI unit connector
EX9-OEP1, EX9-OEP2 (Output block for high wattage load)
Element
Indicator LED
Solenoid valve connector
Output connector (No.0)
Output connector (No.1)
Power block connector
Indicates the output status.
Connected to solenoid valve.
Connects with output device.
Connects with output device.
Connected to SI unit.
Indicates the output status.
Connected to solenoid valve.
Connects with output device.
Connects with output device.
Connected to Power block.
-9-
Function
Function
No.EX※※-OMH0025-C
