•Dimensions when EX126D-SMJ1 is used
L dimensions
n
1
L1 [mm]
127.8
L2 [mm]
115.2
L3 [mm]
111.7
L4 [mm]
106.8
2
3
4
148.8
169.8
190.8
136.2
157.2
178.2
132.7
153.7
174.7
127.8
148.8
169.8
5
6
7
211.8
232.8
253.8
199.2
220.2
241.2
195.7
216.7
237.7
190.8
211.8
232.8
-46-
8
9
10
274.8
295.8
316.8
262.2
283.2
304.2
258.7
279.7
300.7
253.8
274.8
295.8
No.EX※※-OMH0025-C
