•Current consumption in the Power block
Current consumption of the Power block = 20 mA
•Current consumption of the valve load connected to the Output block for high wattage load.
(Current consumption of one valve connected to one output x output number) x Output block number =
(0.5 A x 2 points) x 3 pcs. = (1.0 A) x 3 pcs. = 3 A
Total current consumption = 20 mA + 3 A = 3.02 A
Maximum supply current for Power block = 3.1 A
3.02 A ≦ 3.1 A
Result
OK
-23-
No.EX※※-OMH0025-C
