Type 4 - Directed DS4 Plus Installation Manual

Type 4

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
FT CAN High: Orange/Green, pin 14
FT CAN Low:
Orange/Brown, pin 15
Steering Column Module
(behind steering
1
10
column trim)
Black VESCM connector A
42 25 1
28
29 12
(-) Parking Lights:
Black/White, pin 19
52 41 24 11
(+)12V: Red/Blue or Red/Violet, pin 42
42 25 1
28
29 12
(+) Brake: Black/Red, pin 17
52 41 24 11
Brown VESCM connector C
16
Steering Column Control Unit
20
17
(+) Starter: Red/Black
or Black/Gray,pin 18
[5] Diode 1A
HS CAN High: Orange/Black, pin 6
Diagnostic
1
Connector
9
OBDII
HS CAN Low: Orange/Brown, pin 14
HS CAN High: Tan/Black: 2
FT CAN Low: Orange/Brown: 3
FT CAN High: Orange/Green: 4
(-) Parking Lights Output: Lt.Green/Black: 1
(+) Starter / Brake Activation Output: White: 7
(+) Ignition Output: Violet/Black: 8
(+) Siren Output: Brown/Red: 11
Hood Pin
Siren
(+) 12V Input: Red: 6 & 12
Key Wrap: Lt.Green/Red: 7
Key Wrap: Lt. Green/White: 9
C B
8
16
VESCM - Driver side under dashboard
HS CAN Low: Tan: 1
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
Positioning
Key Wrap: Lt. Green: 8
(-) Ground: Black: 10
Slide
to open
It is important to check that the
fuses are positioned correctly.
© 2017-11-02 Directed. All rights reserved.
).
A
DS4
DS4
DS4+
DS4+ VW10
