Directed DS4 Plus Installation Manual page 27

Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function Color
Volkswagen EOS 2006-2009
12V Red/Black or Black
Parking Light Gray/Yellow
Parking Light Interrupt Red/White
Starter Red/Black
Ignition Black or Black/Green
FT CAN High Orange/Green
FT CAN Low Orange/Brown
HS CAN High Orange/Black
HS CAN Low Orange/Brown
Volksawgen Golf 2006-2009
12V Red/Black or Black
Parking Light Gray/Yellow
Parking Light Interrupt Red/White
Starter Red/Black or Red/Brown
Ignition Black or Black/Green
FT CAN High Orange/Green
FT CAN Low Orange/Brown
HS CAN High Orange/Black
HS CAN Low Orange/Brown
Volkswagen GTI 2006-2009
12V Red/Black or Black
Parking Light Gray/Yellow
Parking Light Interrupt Red/White
Starter Red/Black or Red/Brown
Ignition Black or Black/Green
FT CAN High Orange/Green
FT CAN Low Orange/Brown
HS CAN High Orange/Black
HS CAN Low Orange/Brown
27
Pin Polarity Location
1 (+) VESCM connector L, under drivers dash.
3 (+) Headlight switch.
8 Cut Headlight switch.
1 (+) VESCM connector G, under drivers dash.
11 (+) VESCM connector G, under drivers dash.
8 Data VESCM connector G, under drivers dash.
7 Data VESCM connector G, under drivers dash.
6 Data OBDII.
14 Data OBDII.
1 (+) VESCM connector L, under drivers dash.
3 (+) Headlight switch.
8 Cut Headlight switch.
1 (+) VESCM connector G, under drivers dash.
11 (+) VESCM connector G, under drivers dash.
8 Data VESCM connector G, under drivers dash.
7 Data VESCM connector G, under drivers dash.
6 Data OBDII.
14 Data OBDII.
1 (+) VESCM connector L, under drivers dash.
3 (+) Headlight switch.
8 Cut Headlight switch.
1 (+) VESCM connector G, under drivers dash.
11 (+) VESCM connector G, under drivers dash.
8 Data VESCM connector G, under drivers dash.
7 Data VESCM connector G, under drivers dash.
6 Data OBDII.
14 Data OBDII.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
© 2017-11-02 Directed. All rights reserved.
Pins Ref.
2 A
10 B
10 B
12 C
12 C
12 C
12 C
16 D
16 D
2 A
10 B
10 B
12 C
12 C
12 C
12 C
16 D
16 D
2 A
10 B
10 B
12 C
12 C
12 C
12 C
16 D
16 D
DS4+ VW10
