Type 11 - Directed DS4 Plus Installation Manual

Type 11

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
VESCM -
Driver side, under dashboard
Connector Connector
A
B
16
37 73
(+) 12V:
Red/White
(MUX) Doorlock:
or Red/Yellow,
Blue/Red,pin 24
pin 68
(-) Trunk
Release:
(+) Brake:
Violet, pin 23
Black/Red, pin 39
63
1 17
Black VESCM connector A
(under drivers kick)
Ignition Switch
(black conn. at
ignition switch)
31
White VESCM Connector B
(under drivers kick)
37 73
16
FT CAN Low:
Orange/Brown, pin 21
FT CAN High:
Orange/Green, pin 20
1 17 63
[5] Diode 1A
(+) Starter:
(+) Ignition:
Red/Black, pin 4
Black/Violet, pin 8
9 8 7
10 6
1
5 3
4 2
(+) Accessory: Black/Red, pin 3
HS CAN High: Orange/Black, pin 6
HS CAN Low: Orange/Brown, pin 14
(MUX) Lock/Unlock Output: Violet/Brown: 6
(-) Trunk Release Output: Red/White: 4
(+) Starter/Brake Activation Output: White: 7
(+) Ignition Output: Violet/Black: 8
Hood Pin
Siren
Parking Light Interrupt (conn. side): Blue/White: 1
(+) Parking Light Output: Blue/Red: 2
Parking Light Interrupt (vehicle side): Blue: 3
(+) Accessory Output: White: 5 & 11
Parking Lights Interrupt: Red/Yellow, pin 8
CUT
8 7 6
10 9
Headlight Switch
(black conn. at light switch)
5 2 1
4 3
(+) Parking Lights: White/Black, pin 1
Diagnostic
1 8
Connector OBDII
9 16
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
FT CAN Low: Orange/Brown: 3
FT CAN High: Orange/Green: 4
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
Positioning
(+) 12V Input: Red: 6 & 12
Key Wrap: Lt.Green/Red: 7
Key Wrap: Lt. Green: 8
Key Wrap: Lt. Green/White: 9
(-) Ground: Black: 10
Slide
to open
It is important to check that the
fuses are positioned correctly.
