Type 2; Type 10 - Directed DS4 Plus Installation Manual

Type 2

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
(+) 12V:
Red/White or
Red/Yellow,
42 25 1
pin 42
28
29 12
52 41 24 11
Brown VESCM connector C
11
FT CAN Low: Orange/Brown, pin 3
FT CAN High: Orange/Green, pin 4
(+) Starter: Red/Black or
Red/Brown,pin 6
Steering column module
1 8
6
9 14 16
(behind steering column trim)
(+) Brake: Black/Red, pin 17
[5] Diode 1A
Parking Lights Interrupt:
Red/White, pin 8
8
10
9
5
4 3
(+) Parking Lights: White/Black, pin 1
HS CAN High: Orange/Black, pin 6
Diagnostic
Connector
OBDII
HS CAN Low: Orange/Brown, pin 14
(+) Starter / Brake Activation Output: White: 7
Hood Pin
Siren
Parking Light Interrupt (conn. side): Blue/White: 1
Parking Light Interrupt (vehicle side): Blue: 3
CUT
7
6
Headlight switch
(black conn. at
2 1
light switch)
C
1 8
9 16
VESCM - Driver side under dashboard
HS CAN 1 Low: Tan: 1
HS CAN 1 High: Tan/Black: 2
FT CAN Low: Orange/Brown: 3
FT CAN High: Orange/Green: 4
(+) Ignition Output: Violet/Black: 8
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
(+) Parking Light Output: Blue/Red: 2
Proper Fuse
Positioning
(+) 12V Input: Red: 6 & 12
Key Wrap: Lt.Green/Red: 7
Key Wrap: Lt. Green: 8
Key Wrap: Lt. Green/White: 9
(-) Ground: Black: 10
It is important to check that the
fuses are positioned correctly.
© 2017-11-02 Directed. All rights reserved.
).
B A
DS4+ DS4
DS4
Slide
DS4+
to open
DS4+ VW10
