Directed DS4 Plus Installation Manual page 29

Type 10
Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
VESCM Connector L
(under drivers dash or behind glove box)
10
6 4
2
3 1
(+) Brake:
Black/Red, pin 2
E plug
at VESCM 1 2 3 4
(under
9 10 11 12 13
drivers dash)
Ignition Switch Port
(black conn. at keyport)
Ignition Switch Plug
(at Key Port)
(+) 12V Interrupt: Green/Red, pin 3
CUT
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
Keysense: Green,
pin 16
Fuse 5A
86
29
2
2
1
(+)12V: Red/White, pin 1
VESCM (under drivers dash)
5 6 7
8
16
14 15
Fuse 5A
E F
86 87
85
87a
30
87 85
87a
30
G plug
at VESCM
(under drivers dash)
1 2 3 4 5
(+) Starter:
Red/Gray or
10
7 8 9 11
Red/Violet, pin 1
FT CAN Low:
Orange/ Brown,pin 7
FT CAN High:
Orange/Green,
G
H
pin 8
(-) Key Release Output: Blue/White: 2
(+) Starter / Brake Activcation Output: White: 7
(+) Ignition Output: Violet/Black: 8
Siren
Hood Pin
Parking Light Interrupt (conn. side): Blue/White: 1
(+) Parking Light Output: Blue/Red: 2
Parking Light Interrupt (vehicle side): Blue: 3
Parking Lights Interrupt:
Red/White or Red/Black, pin 8
CUT
8
10 7 6
9
Headlight Switch
(black conn. at light switch)
1
5 4 3 2
(+) Parking Lights: Gray/Yellow, pin 3
HS CAN High:
Orange/Black, pin 6
6
12
1 8
9 16
HS CAN Low:
Orange/Brown, pin 14
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
FT CAN Low: Orange/Brown: 3
FT CAN High: Orange/Green: 4
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
Proper Fuse
Positioning
(+) 12V Input: Red: 6 & 12
Key Wrap: Lt.Green/Red: 7
Key Wrap: Lt. Green: 8
Key Wrap: Lt. Green/White: 9
(-) Ground: Black: 10
Slide
to open
It is important to check that the
fuses are positioned correctly.
© 2017-11-02 Directed. All rights reserved.
).
Diagnostic
Connector OBDII
DS4
DS4
DS4+
DS4+ VW10
