Type 8 - Directed DS4 Plus Installation Manual

Type 8

Refer to "Pre-installation and application warnings" on page 4 for important information, such as the description of special notes referenced in the diagram (
(+) Starter: Red/Black or Black, pin 1
(under drivers dash
or below glove box)
Orange/ Brown,pin 7
Orange/Green, pin 8
VESCM Connector L
(under drivers dash or behind glove box)
10
6 4
2
3 1
24
(under drivers dash or below glove box)
1 2 3 4 5 6
G plug
at VESCM
7 8 9 10 11 12
FT CAN Low:
FT CAN High:
Siren
2
2
1
(+)12V: Pin 1
VESCM
E F G
H
(-) Hazards Output: Lt. Green/Black: 1
Hood Pin
HS CAN High: Orange/Black, pin 6
Diagnostic
Connector 1
OBDII
9
HS CAN Low: Orange/Brown, pin 14
HS CAN Low: Tan: 1
HS CAN High: Tan/Black: 2
FT CAN Low: Orange/Brown: 3
FT CAN High: Orange/Green: 4
(+) Starter Output: White: 7
(+) Ignition Output: Violet/Black: 8
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
DS4+
(+) 12V Input: Red: 6 & 12
Proper Fuse
Positioning
Key Wrap: Lt.Green/Red: 7
Key Wrap: Lt. Green: 8
Key Wrap: Lt. Green/White: 9
(-) Ground: Black: 10
Slide
to open
It is important to check that the
fuses are positioned correctly.
© 2017-11-02 Directed. All rights reserved.
).
8
16
DS4
DS4
DS4+
DS4+ VW10
