Directed DS4 Plus Installation Manual page 28

Wire Information
Function Color
Volkswagen Jetta 2006-2010
12V Red/Black or Red/Yellow
Parking Light Gray/Yellow
Parking Light Interrupt Red/White
Starter Red/Black or Red/Brown
Ignition Black or Black/Green
FT CAN High Orange/Green
FT CAN Low Orange/Brown
HS CAN High Orange/Black
HS CAN Low Orange/Brown
Volkswagen Jetta SportWagen 2009
12V Red/Black
Parking Light Gray/Yellow
Parking Light Interrupt Red/White
Starter Red/Black or Red/Brown
Ignition Black
FT CAN High Orange/Green
FT CAN Low Orange/Brown
HS CAN High Orange/Black
HS CAN Low Orange/Brown
Volkswagen Rabbit 2006-2009
12V Red/Black or Red/Yellow
Parking Light Gray/Yellow
Parking Light Interrupt Red/White
Starter Red/Black or Red/Brown
Ignition Black or Black/Green
FT CAN High Orange/Green
FT CAN Low Orange/Brown
HS CAN High Orange/Black
HS CAN Low Orange/Brown
28
Pin Polarity Location
1 (+) VESCM connector L, under drivers dash.
3 (+) Headlight switch.
8 Cut Headlight switch.
1 (+) VESCM connector G, under drivers dash.
11 (+) VESCM connector G, under drivers dash.
8 Data VESCM connector G, under drivers dash.
7 Data VESCM connector G, under drivers dash.
6 Data OBDII.
14 Data OBDII.
1 (+) VESCM connector L, under drivers dash.
3 (+) Headlight switch.
8 Cut Headlight switch.
1 (+) VESCM connector G, under drivers dash.
11 (+) VESCM connector G, under drivers dash.
8 Data VESCM connector G, under drivers dash.
7 Data VESCM connector G, under drivers dash.
6 Data OBDII.
14 Data OBDII.
1 (+) VESCM connector L, under drivers dash.
3 (+) Headlight switch.
8 Cut Headlight switch.
1 (+) VESCM connector G, under drivers dash.
11 (+) VESCM connector G, under drivers dash.
8 Data VESCM connector G, under drivers dash.
7 Data VESCM connector G, under drivers dash.
6 Data OBDII.
14 Data OBDII.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
Black
© 2017-11-02 Directed. All rights reserved.
Pins Ref.
2 A
10 B
10 B
12 C
12 C
12 C
12 C
16 D
16 D
2 A
10 B
10 B
12 C
12 C
12 C
12 C
16 D
16 D
2 A
10 B
10 B
12 C
12 C
12 C
12 C
16 D
16 D
DS4+ VW10
