- Page 1 933.TL10 DS3+ / DS4+ v2.29.195.3 2017 Toyota Camry (H Key) THTON4 Compatible (Sold Separately)
-
Page 2: Table Of Contents
Contents Introduction Vehicle function compatibilities Pre-installation and application warnings Key type Installation Wiring diagram with T-Harness (THTON4) Wiring diagram with T-Harness (THTON9) Wiring diagram Locating components in the vehicle Vehicle connections Module programming (For security-only programming, see next section.) Module programming for security-only installations Pairing remotes Connecting the module 8556T Temperature Sensor... -
Page 3: Introduction
Introduction This guide provides information on the installation of the DS3/DS3+ and DS4/DS4+ modules as a digital solution. Using these modules in a digital configuration require the module to be flashed with vehicle specific firmware. Refer to our website (www.directechs.com) and click on the DIRECTLINK text in the header for additional information. -
Page 4: Vehicle Function Compatibilities
Vehicle function compatibilities This section lists all the functions compatible with this vehicle for the installation illustrated in this guide. Note: The telematics features listed below (with an asterisk) ONLY apply when using SmartStart. Auto Headlamp Shutoff Accessory Activation Parking Lights Control Ignition Activation Arm Factory Security Remote Start Takeover... -
Page 5: Pre-Installation And Application Warnings
Pre-installation and application warnings Firmware notes: This section highlights important information for this specific firmware and will assist in pricing accordingly, as well as bringing awareness to any operational or vehicle limitations. T-Harness Keys required for Keys required for THTON4 or THTON9 compatible programming operation... -
Page 6: Installation
Wiring diagram with T-Harness (THTON4) Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( THTON4 (optional T-Harness) Refer to the "Vehicle wiring reference chart" for more specific T-harness compatibility. -
Page 7: Wiring Diagram With T-Harness (Thton9)
Wiring diagram with T-Harness (THTON9) Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( Ignition Connector NOT USED Body ECU Connector TPMS Ignition Interrupt (conn. side): Blue/White TPMS Ignition Interrupt (veh. -
Page 8: Wiring Diagram
Wiring diagram Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( Body ECU Connector Body ECU Connector (middle conn. left side of steering column) HS CAN High: SIL Data: Gray, pin 7 Blue, pin 6 Diagnostic... -
Page 9: Locating Components In The Vehicle
Locating components in the vehicle 933.TL10 2.29.195.3 2017 Toyota Camry (H Key) ©2022 VOXX•DEI LLC. All rights reserved. -
Page 10: Vehicle Connections
Vehicle connections The connection information listed below is specific to the 2017 Toyota Camry (H Key). Refer to “Pre-installation and application warnings” for a list of important notes. Data harness, 8-pin white connector (H1) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color... - Page 11 Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H2/22 Violet/White No Connection No Connection Main harness, 12-pin black connector (H3) Module Connects To Conn./Pin Color Description Wire Location (+/-) Wire Color Connection H3/1 Blue/White Passenger Kick, white 18 pin plug, pin 3 Yellow (TPMS) Remote Start Relay N.C.
- Page 12 RF Port harness, 2-pin white connector (H5) Module Conn./Pin Color Description H5/1 RF Loop H5/2 RF Loop D2D harness, 4-pin white (1) and black (2) connectors (H6) Module Conn./Pin Color Description H6/1 Blue (Data) TX H6/2 Black (-) Ground H6/3 Green (Data) RX H6/4...
-
Page 13: Module Programming
Module programming Refer to “LED diagnostics and troubleshooting” for more information and for troubleshooting purposes. (For security-only programming, see next section.) Note: The master key is REQUIRED to complete the module programming successfully. Please ensure that the vehicle is in a safe location, and cannot move forward during programming. -
Page 14: Module Programming For Security-Only Installations
Module programming for security-only installations Refer to "LED diagnostics and troubleshooting" for more information and for troubleshooting purposes. To connect the module: Please ensure that the vehicle is in a safe location and cannot move forward during programming. For vehicles equipped with a manual transmission, make sure the gearshift lever is in the neutral position. -
Page 15: Pairing Remotes
When used in conjunction with Directed SmartStart ® To enable D2D communication between the DS3+/DS4+ and the Directed SmartStart one of the following actions must be performed ® before providing power to the Directed SmartStart unit: ®... -
Page 16: When Used In Conjunction With Smartstart
DO NOT connect the Directed SmartStart ® 2-pin power harness when using the DS3+/DS4+. Power and ground will be provided by the D2D connector on the module. Refer to the Directed SmartStart ® documentation for further details. D2D port configuration Caution! Do not connect the Control Center (antenna) or any digital sensors (8504D) to the white D2D1 port. -
Page 17: Manual Transmission
Manual Transmission IMPORTANT! Directed does not approve nor support installations of manual transmission and remote starts on any electronic vehicles (EV), OEM Remote Start Activation firmware, vehicles with convertibles and/or removable tops, including but not limited to Jeep Wrangler, Honda S2000, Mazda Miata, and other such vehicles. -
Page 18: Led Diagnostics And Troubleshooting
LED diagnostics and troubleshooting This section provides LED diagnostics and troubleshooting information to guide you through the various stages of your installation. Module Programming Description Troubleshooting Make sure the D2D harness is connected and that 12 Volt is present between the red and black wires. If Module has no power. - Page 19 External Module Synchronization Description Troubleshooting OBDII feature not supported. The diagnostic data bus was not detected, therefore the SmartStart features will be limited. (Flashes red, red, then orange) x 10 Active Ground When Running (Status) Description Troubleshooting Ground When Running (Status) command The module has initialized the remote start sequence.
-
Page 20: Soft Reset
Soft reset A module reset will only erase the steps perfomed in “Module Programming”. The firmware and settings flashed to the module will not be affected. Connect all but the If required for your installation, connect all the harnesses to the module, EXCEPT the 12-pin main 12-pin harness power harness. -
Page 21: Tach Learning Procedure (Not Needed With Virtual Tach)
Tach learning procedure (not needed with Virtual Tach) Data Tach: The procedure is not required as the tach comes preprogrammed. However, it is strongly recommended to learn the exact value of the vehicle for the most consistent and reliable starting and functionality. Hardwired Tach: The procedure is required. -
Page 22: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty VOXX DEI LLC (the Company) warrants to the original purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or work- manship within the Lifetime from the date of original purchase in the original vehicle, such defect(s) will be repaired or replaced with new or reconditioned product, (at the Company’s option) without charge for parts or repair labor. -
Page 23: Quick Reference Guide
Factory remote. Press the Remote Start button on the transmitter.* • Aftermarket remote. • Directed SmartStart application via your smartphone. & The parking lights will flash once to indicate the Parking lights flash x1 Press Remote vehicle is now in Pit Stop Mode. - Page 24 The application enables a “Cloud-Connected Car” like never before, providing 2-way interaction with your vehicle. Connectivity is managed through the Directed Cloud Services (DCS) network linking car, app, end user, and the Internet.
