Wiring Connections; Main Harness (H1), 12-Pin Black Connector; Relay Harness (H2), 10-Pin White Connector; Data Harness (H3), 8-Pin White Connector - Directed DS4 Plus Installation Manual

Wiring connections

The wiring connections listed below are specific to this firmware.

Main harness (H1), 12-pin black connector

Conn./Pin Color
H1/1 Blue/White
H1/2 Blue/Red
H1/3 Blue
H1/4 White/Brown
H1/5 White
H1/6 Red
H1/7 Lt. Green/Red
H1/8 Lt. Green
H1/9 Lt. Green/White
H1/10 Black
H1/11 White
H1/12 Red

Relay harness (H2), 10-pin white connector

Conn./Pin Color
H2/1 N/A
H2/2 Red/Black
H2/3 Pink/Black
H2/4 Pink/White
H2/5 Red
H2/6 Green
H2/7 Violet
H2/8 Orange
H2/9 Red/White
H2/10 Pink

Data harness (H3), 8-pin white connector

Conn./Pin Color
H3/1 Tan
H3/2 Tan/Black
H3/3 Orange/Brown
H3/4 Orange/Green
H3/5 Lt. Green
H3/6 Violet/Brown
H3/7 Orange/Black
H3/8 Yellow/Black
1. If these outputs are not used by the firmware, they can be configured by the installer when the module is flashed.
6
Description
Relay 1 N.C. – Parking Light Interrupt (conn. side)
Relay 1 N.O. – (+) Parking Light Output or (+)12V Input
Relay 1 COM – (+) Parking Light Interrupt (vehicle side)
Relay 3 N.C. – No Connection
1
Relay 3 COM – (+) Accessory Output
(+) 12 Volt (Input)
Relay 2 N.O. – Key Wrap
1
Relay 2 COM – Key Wrap
1
Relay 2 N.C. – Key Wrap
1
(-) Ground
Relay 3 COM – (+) Accessory Output
(+) 12 Volt (Input)
Description
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Description
HS CAN Low
HS CAN High
FT CAN Low
FT CAN High
No Connection
(MUX) Lock/Unlock Output
ISO BUS 2
ISO BUS 1
1
1
1
1
1
DS4+ VW10
